FiberThermics Insulated Heating CableProduct Data-Sheet


GENERAL

ThermoSoft is the inventor and manufacturer of patented FiberThermics® heating cables and heating products made with FiberThermics® heating elements. FiberThermics® heating cables comprise flexible, conductive, polymer¬based fibers insulated with various polymers depending on application. FiberThermics® fibers provide the conductivity of conventional metal wires with the flexibility of soft textile threads. FiberThermics® heaters uniquely possess innate thermal cut¬off, whereby the heating fibers act as a continuous thermal fuse for the ultimate safety protection against overheating and fire.



SPECIFICATIONS

Insulation PVC, CrossLinked Polymer, Nylon®, and other chemical and temperature resistant materials
Strengthening Core and Conductor Fiberglass, Polyester, Nylon, FiberThermics® conductive threads
Working Temp. Rating 105°C (221°F) Maximum
Voltage Rating: 480V Maximum
Wattage 15 Wt/ft (49.2 Wt/m) Maximum
Insulation Wall Thickness 7 mils (0.178 mm) Minimum
Final Diameter 39 mils (1.0 mm) Minimum
Resistance 0.5 Ohms/ft ( 1.6 Ohms/m) Minimum
Listings: UL File E207476


.


Questions: contact us>>>
